FEATURE DESCRIPTION:
1. This machine adopts foreign advanced design and automatic controlling systems, combining with the demand of domestic market. It has the advantage of stable performance, high production output and low failure rate.
2. The machine select standard casting iron, steel, the brand electronic appliances, bearing and other components fromGermany,Japanand,Taiwan....
3. The controlling system of the machine adopts PLC terminal controlling, and the parameter set by the LCD touch-screen as the man-machine interface. During running, this equipment has designed the indicator of failure and the alarm system of abrasive raw consumption.
4. This machine is suitable for grinding and polishing large slabs of marble and granite. The conveyor belt advancing speed and the crossbeam moving speed are controlled by frequency converter. The pressure of disc and grinding width are adjustable freely within the setting area.
5. The machine can automatically identify the shape of slabs. Every disc (grinder) can automatically lift up and down according to the identified shapes of slab and tracks recycle the grinding of slabs at the same time. This Model can choose six claws fickert grinder or marble disc.
6. The whole machine is produced by standardized production. Its performance reached the domestic advanced level.
TECHNICAL PARAMETERS:
Model |
Unit |
HLMJD-12C |
HLMJD-16C |
HLMJD-20C |
HLMJD-24C |
Plishing Head QTY. |
pc |
12 |
16 |
20 |
24 |
Useful Working Width |
mm |
600-2100 |
600-2100 |
600-2100 |
600-2100 |
Useful Working Thickness |
mm |
15-50 |
15-50 |
15-50 |
15-50 |
Belt Speed |
mm/min |
0-2500 |
0-2500 |
0-2800 |
0-3200 |
Spindle Motor Power |
kw |
9/11/15 |
9/11/15 |
9/11/15 |
9/11/15 |
Total Power |
kw |
137 |
181 |
203 |
225 |
Water Consumption |
m3/h |
22 |
25 |
26 |
28 |
Overall Size |
mm |
9600*3200*2300 |
11600*3200*2300 |
12600*3200*2300 |
13600*3200*2300 |
