TDH-4C Multi-Heads Continuous Stone Calibrating Machine

  • TDH-4C  Multi-Heads Continuous Stone Calibrating Machine

Product Item: TDH-4C
Category: Stone Polishing Machine
Views: 2311
MAX PROCESSING THICKNESS 100MM
Max processing width 800~2200mm
Power of main motor:11~15 Kw
Belt speed are variable
Product Manual:This is a belt conveying type machine with high speed working efficiency. It use a milling disc plate for grinding and leveling wave stone surface to flat and with uniform thickness.It can greatly imp

Inquiry

You can make an inquiry about this product.
Your e-mail will not be leaked.

  • PRODUCT DETAIL

Products Description:

This is a belt conveying type machine with high speed working efficiency. It use a milling disc plate for grinding and leveling wave stone surface to flat and with uniform thickness.It can greatly improve the polishing efficiency and quality, so to reduce the cost of shine polishing. It can be combined with full automatic stone polishing line.

Technical Datas :

Topland | TDH-2C/4C/6C Multi-heads Stone Thickness Calibrating Machine

Model

Unit

2C

4C

6C

No. Of Heads

2

4

6

Grinding width

mm

300~1200

300~1200

300~1200

Grinding thickness

mm

10~50

10~50

10~50

Main motor power

Kw

18.5/22

18.5/22

18.5/22

Total power

Kw

46.23

62.23

Water consumption

L/min

150

160

180

Overall dimension

mm

4500×2300×2200

6800×2300×2200

8500×2300×2200

Gross weight

Kg

6800

12000

18000
