Thin Stone Slab Cutting Machine
Thin slab cutting machine also named band saw cutting machine is used for slicing slab into two thin pieces. Use a band saw, machine horizontal cutting slab into certain thickness. We have one full production line to make composite slab. This is one of the necessary for slicing .
Machine dimension |
3900×4400×2450 |
mm |
Working table dimension |
2400×1260 |
mm |
Machine occupation area |
≧39 |
m2 |
Water Consumption |
25 |
L/min |
Gross Weight |
4400 |
kg |
Blade size |
(7850)×100×2.2 |
mm |
Max production stone size |
2400×1500 |
mm |
Cutting thickness |
5-170 |
mm |
Working speed |
0-150 |
mm/min |
Rated voltage |
380V 50HZ |
HZ |
Total power |
12 |
kw |
Main motor power |
7.5 |
kw |
Hydraulic pressure oil |
46 |
# |
Working pressure |
5-7 |
Mpa |
